Heavy-Duty Sliding Gate Opener DOG Series | AC/DC Motor for 500–800KG Gates
Product Overview
The DOG series sliding door motors are professional power solutions for modern access control, designed for various commercial and industrial environments. This series offers both AC and DC dual-voltage configurations, covering 500kg and 800kg load models to meet the power needs of different application scenarios. Standard soft-start and soft-stop functions ensure smooth and stable operation; it supports both mechanical and electromagnetic dual limit systems for precise positioning control. With rich external expansion capabilities, a complete door control system integrating safety, convenience, and intelligence can be easily built.
Product Function
Features
Supports one-touch factory reset
Anti-Interference Protection
Safety Protection
Anti-Static
Full Set Of Peripheral Control Ports
Includes door-in-doorport
Electronic lock control port
Warning light port
PB control port
External receiver port
WiFi port
Technical Parameter
Model | Power Supply | Motor Power | Gate Moving Speed | Maximum Loading Weight | Remote Control Distance | Working Duty | Remote Temperature | Working Temperature |
|---|---|---|---|---|---|---|---|---|
SLIDING MOTOR | 110V AC / 60Hz | 150W | 13m/min | 500kg | Single button mode | S2, 20min | 433.92 MHz | -20°C-+70 °C |
SLIDING MOTOR | 220V AC / 60Hz | 170W | 18m/min | 800kg | Three button mode | S2, 20min | 433.92 MHz | -20°C-+70 °C |
FAQs
What gate weight can the DOG Series sliding gate opener support?
The DOG Series is available in 500KG and 800KG load capacities, designed for medium to heavy-duty sliding gates in commercial and industrial applications.
Does the DOG Series support AC/DC power and different voltage standards?
Yes. The sliding gate opener supports AC power input and AC/DC system compatibility, making it suitable for different regional voltage requirements and professional access control systems.
What safety and protection features are included?
The DOG Series includes soft start and soft stop, anti-interference protection, anti-static design, and integrated safety protection to ensure stable and reliable operation in demanding environments.
What control and expansion interfaces are available?
The control board provides multiple peripheral ports, including electronic lock, warning light, push-button control, external receiver, door-in-door, and WiFi ports for flexible system integration.
What limit switch options are supported?
The DOG Series supports both mechanical and electromagnetic limit systems, allowing precise gate positioning and flexible installation.
What environments is the DOG Series suitable for?
With a working temperature range of -20°C to +70°C, the DOG Series is suitable for outdoor and indoor installations in factories, warehouses, commercial buildings, and industrial sites.
