Slim Horizontal Mechanical Combination Switch
Type
Key Selector for Rolling Door Motor
Warranty
1 Year
Application
Door Protection
Place of Origin
China
Brand Name
DEVELOP
Material
zinc alloy
Product Overview
This mechanical lock box is optimized for control panels with limited installation height or those requiring a horizontal layout. Its unique 60mm (height) x 322mm (length) dimensions allow it to be easily integrated into the narrow edges of standard cabinets, instrument panels, or the sides of specialized equipment. Within its compact body, it integrates up to 1000 adjustable mechanical code combinations and boasts excellent electrical characteristics, including a 16A rated current, 3000V AC high dielectric strength, and silver-plated terminals. It is an ideal solution for space-sensitive applications that demand security, flexibility, and reliability.
Key attributes
Model: 16019-12A
Dimensions: L60 x W322 x H48 mm
Combinations: 1-1000 combinations available
Rated Load: Maximum operating current: 16A
Insulation Resistance: 200 MΩ Min
Dielectric Strength: 3000 VAC(50-60HZ)
Materials: Aluminum alloy material, Zinc-alloy cylinder, Metal keys, Powder coating aluminum alloy plate, Silver plated contacts and terminals
FAQs
1. What makes the Key Selector 12A different from standard models?
This model features a slim, horizontal layout (60 x 322 mm), specifically designed for control panels and cabinets with limitedinstallation height or narrow mounting areas.
2. What applications is this selector suitable for?
It is ideal for space-sensitive installations such as industrial cabinets, instrument panels, edge-mounted control systems, andspecialized equipment requiring secure mechanical access control.
3. How secure is the mechanical combination system?
The selector supports 1-1000 adjustable mechanical combinations, enabling flexible keyless access management withoutreliance on electronic power or software.
4. What electrical load can the Key Selector 12A handle?
Model 16019-12A supports a maximum operating current of 16A, making it suitable for controlling motors and industrialelectrical circuits.
5. How does it ensure electrical safety and reliability?
It offers insulation resistance of 200 M and dielectric strength of 3000 VAC (50-6oHz), providing excellent electricalisolation and stable long-term performance.
