China Develop manufactures the TORQEN HH150 automatic sliding door operator, with a 24V brushless DC motor for single doors up to 150 kg and double doors up to 2 × 140 kg. Built for offices, hospitals, retail and public buildings, CE certified, with OEM supply.
HH150 Technical Specifications
Key specifications of the TORQEN HH150 automatic sliding door operator. Open the product page for the full data sheet.
Parameter
HH150
Max door weight
Single door 150 kg · Double door 2 × 140 kg
Door leaf width
500–2,000 mm (customisable)
Opening and closing speed
100–500 mm/s
Motor
24V 55W brushless DC, 2,300 rpm
Hold-open time
0–60 s, adjustable
Power supply
AC 100–240V, 50–60 Hz
Operating temperature
−20 °C to +50 °C
Operating modes
Automatic, always open, partial open, full lock, one way
Safety
Anti-clamp, photocell input, fire alarm terminal, error messages
Options
UPS backup, electronic lock
Also includes self-learning stroke setup, LED display, access keypad terminal and interlock function. CE certified.
What is the maximum door weight?
The HH150 handles single doors up to 150 kg and double doors up to 2 × 140 kg.
Which door widths does it support?
Door leaves from 500 to 2,000 mm, and the configuration can be customised for your project.
Which operating modes are available?
Automatic, always open, partial open, full lock and one way, so the door can follow different traffic needs during the day.
What safety features does it have?
Anti-clamp protection, a photocell input, a fire alarm terminal and error messages for quick diagnostics.
What happens during a power cut?
An optional UPS backup keeps the door working, and an optional electronic lock secures it.
Can it connect to access control?
Yes. It has terminals for an access keypad, access control systems and interlock functions.
Is installation difficult?
No. Automatic stroke learning sets the door travel during commissioning, which reduces setup time for installers.
Can you supply it under our brand?
Yes. We offer OEM supply with your branding and customisable door width configurations.
How do I get a quote?
Use the form on this page or our contact page. Tell us the door size and weight, single or double door, quantity and destination country, and our sales team will reply with pricing and lead time.
